April Product Spotlight of the Month: 3VMS

The 3VMS combines the benefits of the ICM450A programmable 3-phase line voltage monitor and a ICM530 type 1 and type 2 3-phase surge protective device into one easy-to-install solution. The 3VMS protects against both power surges and over/under voltage issues that can cause damage to circuit boards and motors in residential and commercial three-phase 208/240 HVAC equipment.



Overall Features and Benefits of the 3VMS include:

  • All components pre-wired for 208/240 volts
  • Modular design with field replaceable components
  • Field programmable voltage monitor with backlit LCD display and a large fault history
  • Protects against over and under voltage, phase loss, phase reversal, phase unbalance and rapid short cycling
  • Separate 40amp contractor, fully disconnects from the service
  • Superior TMOV technology provides safe and reliable surge protection, up to 150 kA max surge event
  • Built to withstand the high impact of a major surge event
  • NEMA type 4X Rating
  • Limited lifetime product warranty up to a 3-year $10,000 connected equipment warranty.
  • UL Listed: ICM450A UL file number E53944
  • UL Listed: ICM530 UL file number E347279
  • Assembled in the USA



Click here to view the Sell Sheet

Click Here to view the Application Guide



ICM530 Three-Phase Surge Protection Device

The ICM Controls ICM530 is the best that it can get, with a maximum surge current of 150,000 amps and a short circuit rating of 200kA, this control can really take a hit! The ICM530 is a 3-phase surge suppressor designed to safely absorb a surge when it exceeds thermal limits, further protecting your valuable 3-phase equipment.



Below is a list of further details for the ICM530:

  • Delta or Wye Configuration
  • NEMA Type 4X watertight plastic enclosure for outdoor and indoor installation
  • Green LED indicates surge protection present
  • Easily connects to electrical panel or disconnect for indoor and outdoor applications
  • UL Listed Type 1 or Type 2 SPD
  • Limited lifetime product, up to a 3-year $10,000 connected equipment warranty



For more information on product features, benefits and specification see our Sell Sheet and Installation/Application Guide.



ICM450A Programmable 3-Phase Line Voltage Monitor

ICM450A is a flagship line voltage control monitor designed to protect your most valuable equipment. This control provides superior motor protection from premature failure and damage caused by common voltage faults.



Additional features include:

  • Backlit LCD
  • Simultaneous 3-phase true RMS voltage monitoring
  • Factory calibrated
  • 3-phase voltages simultaneously displayed on LCD
  • Fault memory
  • Fault monitoring: High/low voltage, voltage unbalance, phase loss, phase reversal
  • Simple configuration
  • Fully adjustable variables
  • LED indicators
  • Common ¼” quick connect terminations
  • English or Spanish menu options



For more information on product features, benefits and specifications see our Sell Sheet and Installation/Application Guide.



To Learn More About the 3VMS by Watching Our Training Webinar Below:

Interested in Obtaining this Product

Please contact us at orders@icmcontrols.com and we’ll assist you further. If you’d like more product information, please reach out to info@icmcontrols.com and we’d be happy to assist with any technical questions you may have.
