SPECIFICATIONS:
Control Voltage: Line 24V (18-30 VAC), 50/60 Hz
Anticipator Setting: 0.3A plus valve load @ 24 VAC
Prepurge: None
Trial for Ignition: 85 seconds
Flame Failure Response Time: 0.5 seconds
Retry: None
Patents:
– #6,222,719: Ignition Boost
– #5,917,691: Fail Safe Relay Driver
– #5,889,645: Energy Preservation and Transfer Mechanism
– #5,930,104: PWM Relay Actuator Circuit
WEIGHT/DIMENSIONS:
Weight: 0.5
Height: 1.875
Width: 3.125
Length: 4.75
Replaces:
ICM: 294
Johnson Controls: G770RJA-1
York: 025-27762-700
