SPECIFICATIONS:
ICM517A Surge Suppressor
– Maximum Surge Current: 100,000 amps
– Diagnostics green light indicates surge suppression present
– Protection modes: L-L, L-G
– Robust cast aluminum enclosure for secondary safety
ICM492 Voltage Monitor
– User Adjustable settings:
– Voltage set point: 95-280 VAC
– Anti-short cycle time delay: 0-720 seconds
– Over/under voltage setting: 5-25%
– Response time: 0.1 to 10 seconds
– Accuracy: ±2%
Inputs:
– Line voltage: 240 VAC
– Frequency: 50/60 Hz
– Breaker: 40 amp at 240 VAC
Outputs:
– Type: Contactor
– 2-Pole contact ratings: 40A FLA, 240A LRA
WEIGHT/DIMENSIONS:
- Height: 5.18
- Width: 7.97
- Length: 11.95
Replaces:
RectorSeal: RSH-50VRM Kit-DC
